CHINESE ROTARY DRILLING RIG / WATER WELL DRILLING RIG FOR SALE

CHINESE ROTARY DRILLING RIG / WATER WELL DRILLING RIG FOR SALE

    • CHINESE ROTARY DRILLING RIG / WATER WELL DRILLING RIG FOR SALE
    • CHINESE ROTARY DRILLING RIG / WATER WELL DRILLING RIG FOR SALE
  • CHINESE ROTARY DRILLING RIG / WATER WELL DRILLING RIG FOR SALE

    Product Details:

    Place of Origin: China
    Brand Name: Duke
    Certification: CE
    Model Number: LD525

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: 30000-100000USD/SET
    Packaging Details: PLASTIC FILM PLAIN PACKAGING
    Delivery Time: 10 WORKING DAYS
    Payment Terms: L/C, T/T
    Supply Ability: 50 SET PRR QUARTER
    Contact Now
    Detailed Product Description
    Name: CHINESE ROTARY DRILLING RIG / WATER WELL DRILLING RIG FOR SALE Max.drilling Diameter: 1500mm
    Max.drilling Depth: 250m Motor Power: 153kw
    Machine Weight: 26ton Warranty: One Year
    Max.travling Speed: 2.6km/h Type: Rotary Drilling Rig

    CHINESE ROTARY DRILLING RIG / WATER WELL DRILLING RIG FOR SALE



    Rotary drilling machine introduction

    LD525 machine lock rod rotary drilling rig using hydraulic track-type telescopic chassis, self-landing collapsible mast, telescopic drill pipe and many other technical applications, is a suitable for building infrastructure work in the construction machinery. Mainly suitable for sand, clay, powder soil and other geological construction, in perfusion piles, continuous walls, basic reinforcement and other foundation construction has been widely used.



    Rotary drilling machine main tecnical data:

    Item Unit Data
    Model   LD515 LD520 LD525
    Max. Drilling Diameter mm 1800 1600 1500
    Max. Drilling Depth m 15 20 25
    Engine Model   Weifang 6105 Weifang 6105 Cummins C205
    Rated Power kW 113 113 153
    Rated rotation speed rpm 2200 2200 2200
    Rotary Drive Max. output torque kN .m 100 100 100
    Rotary speed r/min 17-45 17-40 17-45
    Pull-Down Cylinder Max.pull-down piston push kN 100 100 100
    Max.pull-down piston pull kN 100 100 100
    Max.pull-down piston stroke mm 2000 3000 2000
    Main Winch Max.pulling force kN 100 100 100
    Max. single-rope speed m/min 70 70 70
    Diameter of steel wire rope mm 24 24 28
    Auxiliary Winch Max.pulling force kN 60 60 60
    Max. single-rope speed m/min 54 54 54
    Diameter of steel wire rope mm 16 16 16
    Traveling Max. traveling speed km/h 2.6 2.6 2.6
    Min.ground claerance mm 340 340 340
    Approach angle ° 21 21 21
    Departure angle ° 18 18 18
    Max.grade ability % 30 30 30
    Weight   t 22 24 26
    Dimension L × W × H mm 8600*2300*3400 9610*2600*3500 10100*2600*3500



    Rotary drilling machine features:

    1. The whole machine shape is small, flexible, especially suitable for a variety of special, narrow, low space industry and civil construction sites.
    2. Structurally optimized two-cylinder boom amplitude mechanism, stable operation, easy to maintain and repair.
    3. The use of rotary drilling rig dedicated hydraulic track chassis, to meet the super stability and transport convenience.
    4. Leading overall transport-type full hydraulic rotary drilling rig, to achieve rapid transition of transport state and construction state.
    5. Power head original patented structure design reasonable, reliable lubrication, strong power, cost savings, and not easy to damage, easy to repair.
    6. Automatic depth, vertical detection, drilling level at any time control.

    CHINESE ROTARY DRILLING RIG / WATER WELL DRILLING RIG FOR SALE 0

    CHINESE ROTARY DRILLING RIG / WATER WELL DRILLING RIG FOR SALE 1



    Why choose us:
    1.All kinds of agreement can be signed with your company if you have any afraid for our products;
    2.Quality is our culture ;
    3.With us your money in safe, your business in safe ;
    4.we think our product will give you an edge over your competitors ;
    5.7*24 hours multi-language professional after-sales service group .



    Company introduction:

    We are located in Zhengzhou City, Henan Province At present, we mainly has two business divisions, drilling rig production and sales division and brand excavator marketing division.
    About drilling rig production and sales Division
    It is mainly produces and sells a variety of well drilling rigs, sub-hole drilling rigs, drilling vehicles and drilling accessories. The company's existing products include 6 series of more than 50 kinds, leading products are: KQZ-100D, KQZ-150D, KQZ-200D submersible drilling rig, FY130, FY150, FY150, FY180, FY200, FY260, FY400, FY600, FY800 and other models of the full-hydraulic driller series, heel tube series, as well as high school low-pressure engineering drill car series.
    About brand excavator Marketing Division
    We have successfully established strategic partnership with Caterpillar, Komatsu, Levo and Sany Group, and become the general agent of excavator sales of this brand in Henan province China. Through us, you will easily buy equipment of high quality and low price.
    Hope we can build good cooperation with you and your company!!!

    CHINESE ROTARY DRILLING RIG / WATER WELL DRILLING RIG FOR SALE 2

    CHINESE ROTARY DRILLING RIG / WATER WELL DRILLING RIG FOR SALE 3
